ColorSquid – Small Magnetic Stirrer

Color Squid White

Small magnetic stirrer with glass surface different motives.

– Digital speed display (LED)

– Electronically controlled motor for more capacity

– Higher speed range from 0 – 2.500 rpm

– Max. stirring quantity 1 l

– Outstanding chemical resistance due to glass top and synthetic bottom made of TPC-ET

– Recyclable materials

Technical data :

– Permissible ambient temperature min. : 5°C

 -Permissible ambient temperature max. : 40°C

– Weight : 0.54kg

– Height : 45mm

– Depth : 160mm

– Permissible relative humidity : 80%

– Voltage : 100 – 240V

– Current consumption : 300mA

– DC Voltage : 12V=

– Power input : 4W

– Frequency : 50/60Hz

– Width : 145mm

– Setting accuracy speed : 50rpm

– Speed display set-value : LED

– Protection class according to DIN EN 60529 : IP 54

– Direction of rotation : right

– Speed control : Turning knob

– Set-up plate material : glass

– Stirring quantity max. per stirring position (H2O) : 1l

– Motor rating output : 2W

– Set-up plate dimensions : Ø 115mm

– Stirring bar length max. : 30mm

– Speed min. : 0rpm

– Speed max. : 2500rpm

– Number of stirring positions : 1
